這種管道獨特的物理設計使使用者能夠輕鬆清潔管子內部，而不影響管子的柔軟性，使得管子能夠在狹小的工作空間中輕鬆操控。
| LARGE PITCH CONVOLUTED TUBING | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part callout | #ID | Size | Braid & Cover | OD | WALL | CONVOLUTIONS | MIN. BEND RADIUS | ||||||
| In. | mm. | In. | mm | In. | mm | In. | mm | In. | mm | In. | mm. | ||
| LPC-01 | 01 | 1/2” | 15 | TO SS PB SS, RC/FP RC/SI KYB | 0.63 0.70 0.80 0.90 0.90 0.76 | 16.1 17.8 20.4 22.8 22.8 19.3 | 0.05 | 1.4 | 0.440 | 11.2 | 1 1/2 1 1/2 1 1/2 2 1/4 2 1/4 1 1/2 | 38 38 38 57 57 38 | |
| LPC-02 | 02 | 3/4” | 20 | TO SS PB SS, RC/FP RC/SI KYB | 0.85 0.91 1.02 1.11 1.11 0.97 | 21.5 23.2 25.8 28.2 28.2 24.7 | 0.05 | 1.4 | 0.620 | 15.7 | 2 2 2 3 3 2 | 51 51 51 76 76 51 | |
| LPC-03 | 03 | 1” | 25 | TO SS PB SS, RC/FP RC/SI KYB | 1.08 1.14 1.25 1.34 1.34 1.20 | 27.4 29.1 31.7 34.1 34.1 30.6 | 0.06 | 1.5 | 0.847 | 21.5 | 2 3/4 2 2/4 2 3/4 4 1/4 4 1/4 2 3/4 | 70 70 70 105 105 70 | |
| LPC-04 | 04 | 1 1/4" | 32 | TO SS PB SS, RC/FP RC/SI KYB | 1.45 1.53 1.72 1.72 1.72 1.57 | 36.8 38.8 43.6 43.8 43.8 40.0 | 0.06 | 1.5 | 1.080 | 27.5 | 3 3/4 3 2/4 3 3/4 4 3/4 4 3/4 3 1/4 | 82 82 82 123 123 82 | |
| LPC-05 | 05 | 1 1/2" | 40 | TO SS PB SS, RC/FP RC/SI KYB | 1.65 1.74 1.92 1.93 1.93 1.78 | 42.0 44.1 48.8 49.1 49.2 45.2 | 0.06 | 1.5 | 1.250 | 32.0 | 4 4 4 6 6 4 | 100 100 100 150 150 100 | |
| LPC-06 | 06 | 2” | 50 | TO SS PB SS, RC/FP RC/SI KYB | 2.11 2.19 2.37 2.38 2.38 2.23 | 53.5 55.6 60.3 60.6 60.6 56.7 | 0.07 | 1.8 | 1.690 | 43.0 | 5 1/2 5 1/2 5 1/2 8 1/4 8 1/4 5 1/2 | 140 140 140 210 210 140 | |
